03 / THE LAB
My homelab.
A documented network design featuring pfSense, MikroTik switching, UniFi wireless and Proxmox virtualisation. VLAN assignments below represent the documented target design; deployment status is not independently verified.
EDGE
Virgin Media → pfSense
Virgin Media Hub in DMZ, forwarding to a dedicated pfSense firewall/router. No native modem mode in the documented setup.
NETWORK
MikroTik + Netgear
CSS326-24G-2S+RM core switch (SwOS) with a GS728TP-100NAS PoE switch downstream. Two UniFi APs connect to PoE trunk ports.
COMPUTE
Two Proxmox nodes
Each Proxmox host connects to a 10G SFP+ port on the core switch. NAS and self-hosted services support the environment.
Network architecture
PUBLIC-SAFE OVERVIEW☁ Internet / Virgin Media
↓
pfSense firewall / inter-VLAN routing
↓ 1G VLAN trunk
MikroTik CSS326 core switch
↙ 10G
Proxmox 1
↓ 1G trunk
Netgear PoE switch
2 UniFi APs · cameras · IoT↘ 10G
Proxmox 2
Simplified diagram based on the supplied topology. Detailed port mappings and private addressing are deliberately omitted.
Network segmentation plan
| VLAN | Name | Purpose | Typical devices |
|---|---|---|---|
| 1 | LAN | Management and trusted clients | PCs, infrastructure management |
| 10 | Servers | Virtualisation and services | Proxmox and server workloads |
| 20 | Guests | Guest wireless clients | Guest devices |
| 30 | IoT | Isolated smart devices | Cameras, doorbell, IoT hubs |
Platforms and services
TrueNAS & OpenMediaVault
NAS storage and file-sharing experimentation, with backups and data integrity as priorities.
Home Assistant
Automations, cameras, sensors and tablet dashboards, with remote access considered separately from administration.
Pi-hole, Tailscale & Cloudflare
DNS filtering, private remote networking and selectively published web applications.
Documentation policy
This public page describes architecture, not a live status dashboard. No admin login URLs, credentials, public IPs, or full firewall configurations are published.
